Acrylic glass engraving CO2 laser cutting machine

Product DescriptionShow detailsFeature1.The laser machine both can engraving & cutting,and scanning functions,and more functions,widely uesed.2.Adopt integrated,stable and reliable design framework.3.All models adoptimported components,ensure the high accuracy,faster speed and longer using life.4.According to process differe

Featured Products

Product Description
CO2 Laser Cutting Machine for Acrylic Glass Carving
CO2 Laser Cutting Machine for Acrylic Glass Carving
CO2 Laser Cutting Machine for Acrylic Glass Carving
CO2 Laser Cutting Machine for Acrylic Glass Carving
Show details
CO2 Laser Cutting Machine for Acrylic Glass Carving

Feature
1.The laser machine both can engraving & cutting,and scanning functions,and more functions,widely uesed.
2.Adopt integrated,stable and reliable design framework.
3.All models adoptimported components,ensure the high accuracy,faster speed and longer using life.
4.According to process different materials,can optional knife strip stable,honeycomb table and flat table.
5.the materials can through the laser machine front and rear,materials lenths is unlimited.
6.LCD controlling panel support various languages and clear display,more convenient operation.
7.Combined with the sophisticated technique computer control,precision machinery,DSP digital control technology,USB data transmission and other high-tech.
Specification
Model
GD 6090 /GD1325/GD1825
X,Y Working Area
600*900/1300*2500/1800*2500MM
Laser power
80/100/130/150/180/200/220/280/300W
Laser type
CO2
Laser head NO.
One ( two heads option)
Reflector and focus mirrors
Imported
Linear rail
Taiwan PMI
Table type
Knife and Honeycomb table
keyword
laser cutting machine,co2 laser cutting machine
Cooling system
Water chiller cw3000
Other accessories
Air pump, Exhausted system,
Engraving Speed
0-60000mm/min
Cutting speed
0-36000mm/min
Resetting position accuracy
±0. 01mm
Control system
RD system
Software
Laser work
Graphic format supported
BMP, PLT, DST, DXF, AI, JPG, GIF, PGN, TIF
Software supported
CorelDraw, PhotoShop, AutoCAD, TAJIMA,Artcut
Laser Output
1-100% Software Setting
Operating temperature
0 - 45ºC
Operating humidity
5 - 95%
Working Mode
3-phase Stepper motor
Dichroic Cutting
Up to 256 colors
Gross power
<2200W
Minimum shaping character
English 1 x 1mm
Working Voltage
220V/50HZ -60HZ; single phase ( 110v option)
Machine Size
1670X1310X1050mm
Packing Size
1780X1420X1260mm
N.W
380KGS
G.W
480KGS
MOQ
1 SET
Application
Applicable Materials: Rubber, plastic, cloth, leather, woollens, crystal, organic glass, tile, jade, bamboo, wood, etc.
Applicable Indusries: Rubber, plastic, cloth toys, leather, computer embroidery cutting, mould, crafts, bamboo and wood,
advertising and building decoration, packaging and printing, paper products.
Typical Application: Acrylic crystal words, acrylic fish tank, ceramic crafts, rubber board printing, applique, special-shaped
trademark, engraving and hollowing out patterns or designs on garment and leather.
CO2 Laser Cutting Machine for Acrylic Glass Carving
CO2 Laser Cutting Machine for Acrylic Glass Carving
Packing & Delivery
CO2 Laser Cutting Machine for Acrylic Glass CarvingCO2 Laser Cutting Machine for Acrylic Glass Carving
FAQ
1. This is the first time I buy the machine, is it easy to operate?
A: We can provide the operation manual or video for guiding. If it is hard for you learning, we can also help you by "Team
viewer" online, with telephone or Skype explain.
2. ARE YOU TRADING COMPANY OR MANUFACTURER ?
A: We are factory.
3. Can I visit your factory?
A: Yes! We greatly welcome customers to visit our factory!
4. What is your MOQ?
A: Our MOQ is 1 set machine. We could send machine to your country port directly, please tell us your port name. There will be best shipping freight and machine price send to you.
Company Profile
Shandong Guandiao CNC Equipment Co., Ltd is an innovative enterprise engaged in research and development, production, sales and good after- sales service. The company's main products include Panel furniture CNC cutting machine, Woodworking CNC Machining Center, CNC router, Multi-head cylinder CNC engraving machine, Styrofoam CNC router, 3D scanner, Vacuum membrane press machine, Vacuum forming machine, Laser engraving and cutting machine, etc. Products applied to the panel furniture, European furniture, solid wood furniture, advertising, stone, building decoration, handicrafts, mold making, staircases column, PCB printing, automotive industry, packaging industry, shipbuilding, wood manufacturing, watches and clocks, accessories, seals and other industries.
CO2 Laser Cutting Machine for Acrylic Glass Carving
CO2 Laser Cutting Machine for Acrylic Glass Carving

After nearly 10 years of development, the company has a perfect technical team, clear labor division, ensuring the high quality products sent to the whole country, to the world.
The company has independent import and export right, products are exported to southeast Asia, the Middle East, Africa, Europe and the United States and other places, and with its excellent quality, excellent performance and perfect after -sales serves won the customer the consistent approval.
